Hikvision MinMoe Face Recognition Terminal (Model: DS-K1T344MBFWX-E1)

Hikvision DS-K1T344MBFWX-E1 – 4.5-Inch Face Recognition Access Control Terminal

The Hikvision DS-K1T344MBFWX-E1 is a professional Face Recognition Access Control Terminal designed to provide fast, secure, and flexible access management for offices, commercial buildings, enterprises, schools, residential properties, financial institutions, and other controlled-entry environments. The Hikvision DS-K1T344MBFWX-E1 combines facial recognition, fingerprint authentication, M1 card access, PIN authentication, and QR code recognition in one compact access control device.

The Hikvision DS-K1T344MBFWX-E1 features a 4.5-inch LCD touch screen with a 480 × 854 resolution and a built-in 2MP wide-angle camera for facial recognition. The Hikvision DS-K1T344MBFWX-E1 uses deep-learning technology to provide fast and accurate face verification, with a facial recognition distance of approximately 0.3 to 1.5 metres, verification duration of less than 0.2 seconds per user, and an accuracy rate of at least 99%.

Supporting multiple authentication methods, the Hikvision DS-K1T344MBFWX-E1 can authenticate users through face, fingerprint, M1 card, PIN, and QR code. It can store up to 3,000 faces, 3,000 fingerprints, and 3,000 cards, while supporting up to 150,000 access events, making the Hikvision DS-K1T344MBFWX-E1 suitable for organizations requiring reliable user and access-event management.

The Hikvision DS-K1T344MBFWX-E1 provides versatile communication and connectivity options, including TCP/IP, Wi-Fi, Bluetooth, USB, RS-485, and Wiegand. The terminal also supports two alarm inputs, one alarm output, door contact input, exit button connection, tamper detection, and relay-based lock control, providing the Hikvision DS-K1T344MBFWX-E1 with the interfaces needed for complete access control installations.

For convenient installation, the Hikvision DS-K1T344MBFWX-E1 supports 12V DC or PoE power, while standard PoE can also support power delivery for the connected door lock under supported configurations. The Hikvision DS-K1T344MBFWX-E1 also supports two-way audio, audio prompts, mobile and PC web configuration, and QR code recognition through its camera.

Built for demanding access-control environments, the Hikvision DS-K1T344MBFWX-E1 features IP65 protection and supports an operating temperature range of -30°C to 60°C. Its wall-mounted design and compact dimensions make the Hikvision DS-K1T344MBFWX-E1 suitable for controlled entrances where space, convenience, and secure authentication are important.

Whether you are securing an office entrance, residential compound, school, hotel, warehouse, or commercial facility, the Hikvision DS-K1T344MBFWX-E1 provides a versatile combination of facial recognition, fingerprint access, card authentication, PIN verification, QR recognition, Wi-Fi, Bluetooth, PoE, and integrated door-control interfaces.

Key Specifications

Product Type: Face Recognition Access Control Terminal
Model: DS-K1T344MBFWX-E1
Operating System: Linux
Display: 4.5-inch LCD Touch Screen
Display Resolution: 480 × 854 pixels
Camera: 2MP Wide-Angle Camera / Dual-Lens Configuration
Face Capacity: Up to 3,000 faces
Fingerprint Capacity: Up to 3,000 fingerprints
Card Capacity: Up to 3,000 M1 cards
Event Capacity: Up to 150,000 events
Authentication Methods: Face / Fingerprint / M1 Card / PIN / QR Code
Face Recognition Distance: 0.3–1.5 metres
Face Recognition Accuracy: ≥99%
Face Verification Duration: <0.2 seconds per user
Card Type: M1, 13.56 MHz
Network: TCP/IP, Wi-Fi, Bluetooth
Communication Interfaces: RS-485 / Wiegand / USB
Alarm Interface: 2 alarm inputs / 1 alarm output
Door Control: Lock control / Exit button / Door contact / Tamper
Audio: Two-way audio and audio prompt
Power Supply: 12V DC / 1A or PoE
PoE: Standard PoE
Protection Rating: IP65
Operating Temperature: -30°C to 60°C
Installation: Wall mounting
Dimensions: 165.2 × 75.7 × 25 mm

Key Features

• AI-powered face recognition uses deep-learning algorithms for fast and accurate user authentication.

• 4.5-inch LCD touch screen provides an intuitive interface for users and administrators.

• 2MP wide-angle camera supports facial recognition and QR code scanning.

• Multi-modal authentication supports face, fingerprint, card, PIN, and QR code access.

• Up to 3,000 face users provides capacity for medium-sized access control deployments.

• Up to 3,000 fingerprints allows biometric fingerprint authentication for registered users.

• Up to 3,000 M1 cards supports contactless card-based access control.

• 150,000 event records provide extensive access-event storage.

• Fast facial verification takes less than 0.2 seconds per user under specified conditions.

• High face recognition accuracy is rated at ≥99%.

• Face anti-spoofing helps improve security against attempts to use unauthorized facial images.

• QR code recognition allows QR codes to be scanned through the camera.

• Wi-Fi and Bluetooth connectivity provide flexible wireless communication options.

• PoE support simplifies power and network connectivity through compatible Ethernet infrastructure.

• Two-way audio supports communication with compatible client software and intercom equipment.

• Wiegand and RS-485 interfaces provide integration options for access-control peripherals.

• Door lock control supports connection to compatible locking hardware.

• Alarm inputs and output support integration with additional security devices.

• IP65 protection helps protect the terminal against dust and water ingress.

• Wide -30°C to 60°C operating range supports installation in demanding environments.

Recommended Applications

The Hikvision DS-K1T344MBFWX-E1 is suitable for:

• Office access control

• Corporate buildings

• Residential compounds

• Apartment buildings

• Schools and educational institutions

• Hotels

• Warehouses

• Retail stores

• Commercial buildings

• Financial institutions

• Industrial facilities

• Staff entrances

• Restricted areas

• Biometric access control systems

• Smart door-entry systems
