Hikvision DS-UPS2000(O-STD)/UK-DS-UPS2000(O-STD)/UK

Hikvision DS-UPS2000(O-STD)/UK – 2000VA/1200W Line-Interactive UPS

The Hikvision DS-UPS2000(O-STD)/UK is a high-capacity 2000VA/1200W Line-Interactive Uninterruptible Power Supply (UPS) designed to provide dependable backup power and protection for CCTV systems, NVRs, networking equipment, computers, workstations, and other critical electronic devices. The Hikvision DS-UPS2000(O-STD)/UK combines battery backup, automatic voltage regulation, surge protection, and intelligent monitoring in a compact tower design.

The Hikvision DS-UPS2000(O-STD)/UK provides a 2000 VA / 1200 W power capacity, making it suitable for supporting multiple connected devices during power interruptions. For security installations, the Hikvision DS-UPS2000(O-STD)/UK can help keep essential surveillance equipment operating when mains power is interrupted.

Featuring a wide input voltage range of 140 VAC to 290 VAC, the Hikvision DS-UPS2000(O-STD)/UK is designed to operate effectively in environments where utility voltage fluctuates. Its built-in Automatic Voltage Regulation (AVR) helps stabilize the incoming power without unnecessarily switching to battery operation.

The Hikvision DS-UPS2000(O-STD)/UK uses two 12 V / 9 Ah sealed lead-acid batteries and supports fast battery charging, with approximately 6–8 hours required to recover to 90% capacity. The Hikvision DS-UPS2000(O-STD)/UK also provides a transfer time of 10 ms or less, helping connected equipment transition quickly to battery backup during an outage.

For convenient monitoring, the Hikvision DS-UPS2000(O-STD)/UK features an LCD display that provides information such as input voltage, output voltage, battery capacity, and load level. A USB interface is also provided for remote control and communication.

The Hikvision DS-UPS2000(O-STD)/UK incorporates multiple protection functions, including overload protection, short-circuit protection, surge protection, and discharge protection. These features help protect connected equipment against common power-related problems.

With its UK Type G plug configuration, the Hikvision DS-UPS2000(O-STD)/UK is a suitable choice for installations requiring UK-style power connectivity. The Hikvision DS-UPS2000(O-STD)/UK is ideal for CCTV control rooms, offices, network cabinets, homes, and other environments where reliable backup power is required.

Choose the Hikvision DS-UPS2000(O-STD)/UK for a dependable combination of 2000VA/1200W capacity, AVR voltage regulation, wide input voltage range, fast charging, LCD monitoring, USB connectivity, and comprehensive power protection.

Key Specifications

Product Type: Line-Interactive Uninterruptible Power Supply (UPS)
Model: DS-UPS2000(O-STD)/UK
UPS Capacity: 2000 VA / 1200 W
Input Voltage Range: 140 VAC to 290 VAC
Input Frequency: 50/60 Hz, self-adaptive
Plug Type: UK Type G
Output Voltage Range: 210 VAC to 235 VAC
Output Frequency: 50 Hz ± 0.5 Hz
Transfer Time: ≤ 10 ms
Waveform: PWM
Battery Type: 12 V / 9 Ah × 2 sealed lead-acid batteries
Battery Recharge Time: 6–8 hours to 90% capacity
Typical Backup Time: Approximately 70 min at 100 W; 17 min at 300 W; 5 min at 600 W
Display: LCD display
Communication Interface: USB
Protection: Surge, overload, discharge and short-circuit protection
AVR: Built-in Automatic Voltage Regulation
Operating Temperature: 0°C to 40°C
Operating Humidity: 30% to 90%, non-condensing
Dimensions: 345 × 122 × 192 mm
Weight: Approximately 11 kg

Key Features

• 2000VA / 1200W capacity supports multiple connected electronic devices.

• Line-interactive UPS technology provides dependable backup power and voltage regulation.

• Built-in AVR helps stabilize fluctuating input voltage.

• Wide 140–290 VAC input range allows operation across a broad range of utility voltage conditions.

• UK Type G plug makes this version suitable for UK-style power connections.

• Super-fast charging helps restore battery capacity efficiently.

• Two 12V/9Ah batteries provide the internal backup power source.

• ≤10 ms transfer time enables rapid transition to battery power.

• LCD display provides convenient real-time monitoring of UPS operating conditions.

• USB communication port supports remote control and monitoring.

• Surge protection helps protect connected equipment against power surges.

• Overload protection helps prevent damage when connected loads exceed the UPS capacity.

• Short-circuit protection provides additional protection against electrical faults.

• Discharge protection helps protect the internal batteries.

• Audible alarms provide notifications for low battery, overload, charging and fault conditions.

• Compact tower design makes the UPS practical for offices, security rooms and equipment areas.

• Suitable for CCTV systems including NVRs, DVRs, PoE switches and other surveillance equipment.

• Suitable for networking equipment including routers, switches and communication devices.

• Wide operating temperature range of 0°C to 40°C supports different indoor environments.

Recommended Applications

The Hikvision DS-UPS2000(O-STD)/UK is suitable for:

• CCTV surveillance systems

• NVR and DVR systems

• IP camera installations

• PoE network switches

• Routers and networking equipment

• Computers and workstations

• Small servers

• Offices

• Homes and home offices

• Security control rooms

• Retail stores

• Commercial buildings

• Communication equipment

• Access control systems
