8-port Fast Ethernet Smart Managed PoE Switch-DS-3E1309P-EI/M

Hikvision DS-3E1309P-EI/M – 8-Port Fast Ethernet Smart PoE Switch

The Hikvision DS-3E1309P-EI/M is an 8-Port Fast Ethernet Smart PoE Switch designed for IP surveillance systems, small and medium-sized networks, offices, retail stores, schools, warehouses, and commercial installations. The Hikvision DS-3E1309P-EI/M provides 8 × 10/100 Mbps PoE ports and 1 × Gigabit RJ45 uplink port, making it suitable for connecting IP cameras, NVRs, access points, and other network devices.

The Hikvision DS-3E1309P-EI/M supports IEEE 802.3af and IEEE 802.3at PoE standards, allowing compatible devices to receive power and data through a single Ethernet cable. With a 60 W total PoE power budget and up to 30 W per PoE port, the Hikvision DS-3E1309P-EI/M provides a practical power solution for multiple PoE-enabled security devices.

The Hikvision DS-3E1309P-EI/M delivers a 3.6 Gbps port switching capacity and a 2.6784 Mpps packet forwarding rate, providing efficient traffic handling for Fast Ethernet surveillance networks. Its 8K MAC address table allows the switch to learn and manage connected network devices.

For CCTV installations, the Hikvision DS-3E1309P-EI/M supports Long Range PoE transmission of up to 300 metres in Extend mode, making it suitable for surveillance projects where cameras are installed beyond the standard Ethernet transmission distance. Actual transmission performance may vary depending on the camera model and cable condition.

The Hikvision DS-3E1309P-EI/M also features PoE Watchdog, which automatically detects and restarts connected cameras that stop responding. This can help reduce the need for manual intervention and improve the reliability of remote surveillance installations.

For network management, the Hikvision DS-3E1309P-EI/M supports 802.1Q VLAN, STP/RSTP loop prevention, cable detection, port isolation, flow control, and remote device maintenance. These features make the Hikvision DS-3E1309P-EI/M suitable for installations requiring more than basic unmanaged switching.

The Hikvision DS-3E1309P-EI/M uses a fan-free metal housing and supports desktop or wall-mounted installation. It also provides 6 kV surge protection for additional protection of connected PoE equipment in suitable installations.

If you need a compact smart PoE switch for an IP surveillance system, the Hikvision DS-3E1309P-EI/M offers a strong combination of 8 PoE ports, 60 W PoE budget, Gigabit uplink, 300 m Long Range PoE, PoE Watchdog, VLAN support, 6 kV surge protection, and smart network management.

Key Specifications

Product Type: 8-Port Fast Ethernet Smart PoE Switch
Model: DS-3E1309P-EI/M
PoE Ports: 8 × 10/100 Mbps PoE RJ45 ports
Uplink Port: 1 × Gigabit RJ45 port
Port Speed: 10/100 Mbps PoE / 10/100/1000 Mbps uplink
Switching Capacity: 3.6 Gbps
Packet Forwarding Rate: 2.6784 Mpps
MAC Address Table: 8K
Internal Cache: 4 Mbits
PoE Standard: IEEE 802.3af / IEEE 802.3at
PoE Power Budget: 60 W
Maximum PoE Power per Port: 30 W
Long Range PoE: Up to 300 metres in Extend mode
VLAN: IEEE 802.1Q
Loop Prevention: STP / RSTP
Surge Protection: 6 kV
Housing: Metal, fan-free design
Power Supply: 54 V DC, 1.2 A
Maximum Power Consumption: 65 W
Installation: Desktop / Wall-mounted
Operating Temperature: 0°C to 40°C

Key Features

• 8 × 10/100 Mbps PoE ports provide network connectivity and power for compatible IP cameras.

• 1 × Gigabit RJ45 uplink port provides a high-speed connection to an NVR, router, or larger network.

• 60 W PoE power budget supports multiple PoE-powered devices.

• IEEE 802.3af/at support provides compatibility with standard PoE and PoE+ devices.

• Up to 30 W per PoE port supports compatible higher-power devices.

• Up to 300 m Long Range PoE enables extended-distance IP camera deployments.

• PoE Watchdog automatically detects and restarts cameras that become unresponsive.

• 802.1Q VLAN support enables network traffic segmentation.

• STP/RSTP loop prevention helps prevent network loops.

• Cable detection helps locate cable faults and connection problems.

• Port isolation helps improve network security between connected devices.

• Flow control helps regulate network traffic and improve transmission stability.

• 8K MAC address table provides capacity for connected network devices.

• 3.6 Gbps switching capacity supports efficient Fast Ethernet traffic processing.

• 2.6784 Mpps forwarding rate provides efficient packet forwarding.

• 6 kV surge protection helps protect PoE ports against electrical surges.

• Remote maintenance support allows firmware upgrades, log viewing, and basic network configuration.

• Network topology and health monitoring support easier surveillance network maintenance.

• Fan-free metal housing provides quiet operation and durable construction.

• Desktop and wall-mounted installation provides flexible deployment options.

Recommended Applications

The Hikvision DS-3E1309P-EI/M is suitable for:

• IP CCTV surveillance systems

• Small and medium-sized camera installations

• NVR networks

• Offices and business premises

• Retail stores

• Schools and educational institutions

• Warehouses

• Hotels

• Commercial buildings

• Long-distance IP camera installations

• PoE access point deployments

• Security monitoring systems

• Network infrastructure
