Hikvision DS-3E0105D-O – 5-Port 100 Mbps Unmanaged Fast Ethernet Desktop Switch

The Hikvision DS-3E0105D-O is a compact 5-Port 100 Mbps Unmanaged Fast Ethernet Desktop Switch designed to provide simple, reliable, and affordable wired network expansion for homes, offices, schools, small businesses, and basic CCTV installations. The Hikvision DS-3E0105D-O features five 10/100 Mbps RJ45 Ethernet ports and is designed for straightforward plug-and-play networking without complicated configuration.

The Hikvision DS-3E0105D-O provides a 1 Gbps switching capacity and a 0.74 Mpps packet forwarding rate, making it suitable for everyday Fast Ethernet network applications. The Hikvision DS-3E0105D-O uses store-and-forward switching technology to efficiently process network traffic between connected devices.

With five 10/100 Mbps RJ45 ports, the Hikvision DS-3E0105D-O can connect computers, network printers, IP cameras, NVRs, routers, and other Ethernet-enabled devices. The Hikvision DS-3E0105D-O is an unmanaged switch, meaning users can simply connect their network cables and begin using the switch without requiring advanced network configuration.

The Hikvision DS-3E0105D-O features a 2K MAC address table, allowing it to learn and maintain the addresses of connected network devices. Its 768 Kbit internal cache provides packet buffering, helping support reliable network communication.

Designed for convenient installation, the Hikvision DS-3E0105D-O uses a lightweight ABS plastic housing and can be installed on a desktop. The compact 83 × 22 × 52 mm design makes the Hikvision DS-3E0105D-O suitable for installations where space is limited.

The Hikvision DS-3E0105D-O also provides 2 kV surge protection, adding an extra layer of protection for the switch against electrical surges. The switch operates from a 5V DC, 0.6A power supply and has a maximum power consumption of approximately 3W.

For CCTV and small network applications, the Hikvision DS-3E0105D-O provides an economical way to expand Ethernet connectivity. The Hikvision DS-3E0105D-O is particularly suitable for small surveillance networks, offices, classrooms, homes, shops, and other environments that do not require Gigabit Ethernet or PoE.

If you need a compact and easy-to-use network switch, the Hikvision DS-3E0105D-O offers an effective combination of five 10/100 Mbps Ethernet ports, unmanaged operation, 1 Gbps switching capacity, 2K MAC address capacity, 2 kV surge protection, ABS construction, and desktop installation.

Key Specifications

Product Type: 5-Port 100 Mbps Unmanaged Fast Ethernet Switch
Model: DS-3E0105D-O
Ports: 5 × 10/100 Mbps RJ45 Ethernet ports
Port Speed: 10/100 Mbps Fast Ethernet
Switching Capacity: 1 Gbps
Packet Forwarding Rate: 0.74 Mpps
MAC Address Table: 2K
Internal Cache: 768 Kbit
Forwarding Mode: Store-and-forward
Management: Unmanaged
Housing: ABS plastic
Surge Protection: 2 kV
Power Supply: 5V DC, 0.6A
Maximum Power Consumption: 3W
Dimensions: 83 × 22 × 52 mm
Net Weight: Approximately 0.093 kg
Installation: Desktop / Wall-mounted
Operating Temperature: 0°C to 40°C
Operating Humidity: 5%–95%, non-condensing
PoE: Not supported

Key Features

• 5 × 10/100 Mbps RJ45 ports provide reliable Fast Ethernet connectivity.

• Unmanaged operation offers simple plug-and-play network installation.

• 1 Gbps switching capacity supports efficient traffic handling between connected devices.

• 0.74 Mpps forwarding rate provides reliable packet forwarding performance.

• 2K MAC address table allows the switch to learn and maintain connected device addresses.

• 768 Kbit internal cache provides temporary packet buffering.

• Store-and-forward switching helps provide reliable network packet transmission.

• 2 kV surge protection provides additional protection against electrical surges.

• ABS plastic housing provides a lightweight and compact construction.

• Desktop installation allows convenient placement in homes, offices, shops, and small network environments.

• Wall-mounting capability provides additional installation flexibility.

• Plug-and-play design requires no complicated network configuration.

• 10/100 Mbps Ethernet support provides compatibility with standard Fast Ethernet devices.

• CCTV network support makes the switch suitable for basic IP surveillance installations.

• Low power consumption helps provide efficient everyday operation.

• Compact dimensions make the switch suitable for space-constrained network installations.

• Non-PoE design provides network connectivity without delivering power over Ethernet.

Recommended Applications

The Hikvision DS-3E0105D-O is suitable for:

• Home networks

• Small offices

• SOHO environments

• Schools and classrooms

• Retail stores

• Small businesses

• IP CCTV systems

• NVR networks

• Network printers

• Computer networks

• Router network expansion

• Small monitoring rooms

• Basic Ethernet network installations.
