5-Port Gigabit Desktop Switch-DS-3E0505D-O

Hikvision DS-3E0505D-O – 5-Port Gigabit Unmanaged Desktop Switch

The Hikvision DS-3E0505D-O is a compact 5-Port Gigabit Unmanaged Desktop Switch designed to provide reliable and high-speed Ethernet connectivity for homes, offices, small businesses, CCTV systems, and other network environments. The Hikvision DS-3E0505D-O provides five Gigabit RJ45 Ethernet ports supporting 10/100/1000 Mbps connectivity, making it suitable for connecting network cameras, NVRs, computers, printers, routers, and other Ethernet devices.

The Hikvision DS-3E0505D-O delivers a 10 Gbps switching capacity and a 7.44 Mpps packet forwarding rate, allowing connected devices to communicate efficiently across the local network. The Hikvision DS-3E0505D-O uses store-and-forward switching technology to help provide reliable packet transmission and network performance.

With five Gigabit RJ45 ports, the Hikvision DS-3E0505D-O provides a straightforward way to expand an existing wired network without requiring complicated configuration. As an unmanaged switch, the Hikvision DS-3E0505D-O is designed for simple plug-and-play deployment, making it particularly suitable for users who need basic Gigabit network expansion without advanced network management.

The Hikvision DS-3E0505D-O supports MAC address auto-learning and aging, helping the switch automatically manage connected device addresses. Its 2K MAC address table provides capacity for maintaining learned network-device information. The Hikvision DS-3E0505D-O also incorporates a 1 Mbit internal cache for temporary packet buffering.

Designed with a compact ABS housing, the Hikvision DS-3E0505D-O has a lightweight construction of approximately 0.059 kg and dimensions of 87 × 25 × 51 mm. Its small desktop form factor makes the Hikvision DS-3E0505D-O convenient for installations where available space is limited.

The Hikvision DS-3E0505D-O is powered by 5V DC at 0.6A and is designed for desktop installation. Its operating temperature range of 0°C to 40°C and operating humidity range of 5% to 95% non-condensing make the Hikvision DS-3E0505D-O suitable for typical indoor networking environments.

For CCTV and networking applications, the Hikvision DS-3E0505D-O can be used to connect compatible IP cameras, NVRs, computers, routers, and other Ethernet devices. The Hikvision DS-3E0505D-O provides a cost-effective solution for small surveillance and network installations requiring Gigabit Ethernet connectivity.

If you need a compact and easy-to-install network switch, the Hikvision DS-3E0505D-O offers an effective combination of 5 Gigabit Ethernet ports, 10 Gbps switching capacity, 7.44 Mpps forwarding performance, 2K MAC address capacity, plug-and-play operation, and a compact ABS housing.

Key Specifications

Product Type: 5-Port Gigabit Unmanaged Desktop Switch
Model: DS-3E0505D-O
Port Number: 5 × Gigabit RJ45 ports
Port Speed: 10/100/1000 Mbps
Switching Capacity: 10 Gbps
Packet Forwarding Rate: 7.44 Mpps
MAC Address Table: 2K
Internal Cache: 1 Mbit
Forwarding Mode: Store and Forward
Network Functions: MAC address auto-learning and aging
Housing: ABS plastic
Power Supply: 5V DC, 0.6A
Operating Temperature: 0°C to 40°C
Operating Humidity: 5% to 95%, non-condensing
Dimensions: 87 × 25 × 51 mm
Net Weight: Approximately 0.059 kg
Installation: Desktop-mounted
Management: Unmanaged
PoE: Not supported

Key Features

• 5 Gigabit RJ45 ports provide 10/100/1000 Mbps Ethernet connectivity.

• 10 Gbps switching capacity provides high-speed switching between connected devices.

• 7.44 Mpps packet forwarding rate supports efficient network traffic handling.

• Unmanaged operation provides simple plug-and-play network installation.

• Store-and-forward switching helps ensure reliable packet transmission.

• MAC address auto-learning and aging automatically manages connected device addresses.

• 2K MAC address table supports a broad range of connected network devices.

• 1 Mbit internal cache provides packet buffering for network traffic.

• Compact ABS housing provides a lightweight and practical desktop design.

• Low power requirement uses a 5V DC, 0.6A power supply.

• Small footprint makes the switch suitable for space-constrained installations.

• Gigabit connectivity is suitable for high-bandwidth local network applications.

• CCTV compatibility makes it suitable for connecting IP cameras and NVR systems.

• Plug-and-play design minimizes configuration requirements.

• Indoor desktop installation provides convenient deployment in offices and network cabinets or work areas.

• Lightweight construction makes transportation and installation easy.

Recommended Applications

The Hikvision DS-3E0505D-O is suitable for:

• CCTV network installations

• IP camera systems

• NVR connections

• Small offices

• Homes and residential networks

• Small businesses

• Retail stores

• Schools

• Computer networks

• Printers and network peripherals

• Routers and network expansion

• Small surveillance environments

• Desktop Ethernet expansion
