4MP standalone, solar-powered 4G Pan-Tilt (PT) network camera-DS-2CFSP4/4G

Hikvision DS-2CFSP4/4G – 4MP 24/7 Solar 4G PT Camera

The Hikvision DS-2CFSP4/4G is a high-performance 4MP 24/7 Solar 4G PT Camera designed for reliable outdoor surveillance in locations where conventional power and network cabling may be unavailable. Combining solar power, a built-in lithium battery and 4G LTE connectivity, the camera provides a flexible security solution for farms, estates, construction sites, roads, parks, plantations and other remote locations.

Featuring a 1/3-inch Progressive Scan CMOS image sensor and a maximum resolution of 2560 × 1440 pixels, the Hikvision DS-2CFSP4/4G delivers detailed 4MP video surveillance. The camera is available with 2.8mm or 4mm fixed focal lens options, allowing installers to select an appropriate field of view for the surveillance area.

The Hikvision DS-2CFSP4/4G supports AOV mode for 24/7 video recording while maintaining ultra-low power consumption. Its integrated 8W solar panel and 9000mAh lithium battery help provide an off-grid surveillance solution without requiring traditional network or power cables.

For effective day and night surveillance, the camera uses Smart Hybrid Light technology with both infrared and white-light illumination up to 30 metres. This helps the Hikvision DS-2CFSP4/4G provide flexible night monitoring and improved visibility in low-light environments.

The PT design supports remote movement, while Smart Tracking can automatically follow detected people. Motion Detection 2.0 supports person and vehicle detection, helping improve the relevance of security events and alerts.

Built-in microphone and speaker hardware supports two-way audio, allowing users to communicate through the camera when using compatible remote monitoring features. With an IP66 weather-resistant rating, the Hikvision DS-2CFSP4/4G is designed for dependable outdoor security monitoring in challenging environments.

Key Specifications

Brand: Hikvision
Model Number: DS-2CFSP4/4G
Product Type: Solar-Powered 4G PT Network Camera
Maximum Resolution: 4MP, 2560 × 1440 pixels
Image Sensor: 1/3-inch Progressive Scan CMOS
Lens Options: 2.8mm or 4mm fixed focal lens
Aperture: F1.28
Lens Mount: M12
Minimum Illumination: Colour: 0.005 Lux @ F1.2, AGC ON; 0 Lux with IR
Day/Night Function: IR Cut Filter
Shutter Time: 1s to 1/100,000s
Pan Range: 0° to 340°
Tilt Range: 0° to 80°
Pan Speed: Up to 20°/s
Tilt Speed: Up to 25°/s
Supplement Light Type: IR and White Light
Supplement Light Range: Up to 30 metres
IR Wavelength: 850nm
Smart Supplement Light: Yes
Video Compression: H.265
Maximum Frame Rate: Up to 15 fps at 60Hz
Video Bit Rate: 32 Kbps to 8 Mbps
Connectivity: 4G LTE
SIM Type: Nano SIM
Storage: Supports local storage; supported capacity depends on configuration
Motion Detection: Motion Detection 2.0
Target Detection: Person and Vehicle Detection
Smart Tracking: Supported
Audio: Built-In Microphone and Speaker
Two-Way Audio: Supported
Recording Mode: AOV Mode with 24/7 Video Recording Support
Solar Panel: 8W
Battery Capacity: 9000mAh Lithium Battery
Battery Life Cycle: More than 800 cycles
Power Supply: Solar and Battery System
Weather Protection: IP66
Operating Temperature: 0°C to 50°C
Camera Material: Plastic
Camera Dimensions: Approximately 208 × 131 × 282.7mm
Camera Weight: Approximately 850g

Key Features

• 4MP High-Resolution Surveillance: Delivers video at up to 2560 × 1440 resolution.

• Solar-Powered Operation: Includes an 8W solar panel for off-grid surveillance applications.

• 9000mAh Lithium Battery: Provides stored power for continuous operation.

• 4G LTE Connectivity: Enables remote connectivity without conventional wired internet infrastructure.

• AOV Mode: Supports 24/7 video recording with ultra-low power consumption.

• PT Camera Design: Supports remote pan and tilt adjustment for flexible surveillance coverage.

• Smart Tracking: Can automatically track detected people.

• Motion Detection 2.0: Supports person and vehicle detection.

• Smart Hybrid Light: Combines infrared and white-light illumination.

• 30-Metre Supplement Light Range: Supports night monitoring with IR and white light.

• Built-In Microphone: Captures audio for compatible monitoring applications.

• Built-In Speaker: Supports two-way audio communication.

• H.265 Video Compression: Helps optimise video storage and transmission efficiency.

• IP66 Weather Protection: Designed to resist dust and water exposure in outdoor installations.

• 2.8mm and 4mm Lens Options: Provides flexibility for different surveillance requirements.

• No Conventional Power Cabling Required: Suitable for remote and difficult-to-wire locations.

• No Conventional Network Cabling Required: 4G connectivity supports flexible deployment.

• Remote Monitoring: Compatible with supported Hikvision remote monitoring platforms.

• Outdoor Surveillance Solution: Suitable for farms, estates, roads and construction sites.

Recommended Applications

• Farms and agricultural facilities

• Plantations and rural properties

• Construction sites

• Estates and private properties

• Roads and roadside monitoring

• Parks and open public spaces

• Remote business locations

• Temporary surveillance installations

• Off-grid security monitoring

• Outdoor storage areas

• Remote infrastructure sites

• Locations without fixed broadband connections

• Locations where power cabling is difficult or expensive

1_year
