4 MP Smart Hybrid Light Fixed Bullet Network Camera-DS-2CD2T47G3-LIS2UY/SRB(2.8mm)

Hikvision DS-2CD2T47G3-LIS2UY/SRB(2.8mm) – 4MP Smart Hybrid Light with ColorVu Fixed Bullet Network Camera

The Hikvision DS-2CD2T47G3-LIS2UY/SRB(2.8mm) is a high-performance 4MP Smart Hybrid Light with ColorVu Fixed Bullet Network Camera designed for professional outdoor and perimeter surveillance. It combines high-resolution imaging, advanced low-light performance, intelligent deep-learning analytics, dual-microphone audio and active deterrence features to provide a comprehensive IP security solution.

Featuring a 1/1.8-inch Progressive Scan CMOS image sensor, the camera delivers a maximum resolution of 2688 × 1520 pixels. Its large-aperture F1.0 2.8mm fixed lens and ColorVu technology support exceptionally low-light colour imaging, helping maintain detailed surveillance around the clock.

The 2.8mm fixed focal lens provides a wide field of view of approximately 111.1° horizontally, 57.6° vertically and 138.5° diagonally, making the camera suitable for monitoring entrances, driveways, building perimeters, car parks and other wide outdoor areas.

Smart Hybrid Light technology integrates infrared and white-light illumination and provides up to 60 metres of supplemental lighting range. The camera supports flexible lighting operation, helping deliver effective night surveillance while allowing colour imaging when white-light illumination is required.

The Hikvision DS-2CD2T47G3-LIS2UY/SRB(2.8mm) also includes an arrayed dual-microphone system for real-time, high-quality audio security and supports built-in two-way audio. Intelligent analytics focus on person and vehicle classification, while perimeter protection supports events such as line crossing, intrusion, region entrance and region exiting.

For enhanced active deterrence, the SRB model features red and blue flashing lights, combined with audio alarm capability to help warn intruders away. The camera also features an anti-corrosion design rated to NEMA 4X, together with IP67 dust and water protection, making it suitable for demanding outdoor surveillance installations.

With support for 12V DC and PoE+ (IEEE 802.3at), the Hikvision DS-2CD2T47G3-LIS2UY/SRB(2.8mm) offers flexible installation for professional network surveillance systems requiring high-quality colour imaging, intelligent detection, active deterrence and durable outdoor protection.

Key Specifications

Brand: Hikvision
Model Number: DS-2CD2T47G3-LIS2UY/SRB(2.8mm)
Product Type: Smart Hybrid Light with ColorVu Fixed Bullet Network Camera
Image Sensor: 1/1.8-inch Progressive Scan CMOS
Maximum Resolution: 2688 × 1520 pixels
Resolution: 4MP
Lens: 2.8mm Fixed Focal Lens
Lens Mount: M16
Aperture: F1.0
Horizontal Field of View: 111.1°
Vertical Field of View: 57.6°
Diagonal Field of View: 138.5°
Depth of Field: 2.5m to Infinity
Minimum Illumination: 0.0001 Lux @ F1.0, AGC ON; 0 Lux with Supplemental Light
Day/Night Function: IR Cut Filter
Supplement Light Type: Infrared and White Light
Supplement Light Range: Up to 60 metres
IR Wavelength: 850nm
Smart Supplement Light: Yes
Video Compression: H.265+ / H.265 / H.264+ / H.264
Maximum Main Stream Frame Rate: Up to 30 fps at 2688 × 1520
Wide Dynamic Range: Scene-Adaptive WDR
Image Processing: HikAI-ISP
Noise Reduction: Advanced Noise Reduction Processing
Colour Imaging: 24/7 ColorVu Imaging
Face Capture: Supported
Perimeter Protection: Line Crossing, Intrusion, Region Entrance and Region Exiting
Target Classification: Human and Vehicle Classification
Audio: Built-In Arrayed Dual Microphones
Audio Communication: Built-In Two-Way Audio
Active Deterrence: Flashing Light and Audio Alarm
Flashing Light: Red and Blue Light for SRB Model
Audio Interface: Available
Alarm Interface: Available
Network Camera Type: Fixed Bullet Network Camera
Power Supply: 12V DC ±25%
PoE: IEEE 802.3at, Class 4
Maximum Power Consumption: Up to 18W with PoE
Weather Protection: IP67
Anti-Corrosion Protection: NEMA 4X
Housing Material: Metal Front Cover, Metal Body and Metal Bracket
Pan Adjustment: 0° to 360°
Tilt Adjustment: 0° to 90°
Rotation Adjustment: 0° to 360°
Operating Temperature: -30°C to 60°C
Dimensions: Approximately 286.7 × 93.3 × 91.2mm
Weight: Approximately 1250g
Installation: Indoor and Outdoor Surveillance

Key Features

• 4MP High-Resolution Imaging: Delivers detailed video at up to 2688 × 1520 pixels.

• 1/1.8-Inch Large Image Sensor: Supports improved image capture and low-light performance.

• ColorVu Technology: Supports colourful imaging in extremely low-light environments.

• 2.8mm Wide-Angle Lens: Provides approximately 111.1° horizontal coverage.

• F1.0 Large Aperture: Supports enhanced light collection for low-light surveillance.

• Smart Hybrid Light: Combines infrared and white-light illumination.

• Up to 60 Metres of Supplemental Light: Supports effective long-range night surveillance.

• HikAI-ISP Processing: Helps improve image processing and noise reduction.

• Scene-Adaptive WDR: Helps improve image visibility in scenes with changing lighting conditions.

• Person and Vehicle Classification: Helps provide more relevant surveillance events.

• Perimeter Protection: Supports line crossing, intrusion, region entrance and region exiting detection.

• Face Capture: Supports compatible face capture functions.

• Arrayed Dual Microphones: Supports improved real-time audio monitoring.

• Built-In Two-Way Audio: Enables real-time communication through compatible surveillance systems.

• Red and Blue Active Deterrence Lights: The SRB version uses flashing red and blue lights to help deter intruders.

• Audio Alarm Capability: Provides additional active security warning functionality.

• H.265+ Compression: Helps optimise video bandwidth and storage requirements.

• PoE+ Support: Allows power and data transmission through a compatible Ethernet connection.

• IP67 Protection: Designed to resist dust and water exposure.

• NEMA 4X Anti-Corrosion Design: Provides enhanced durability in demanding environments.

• Metal Construction: Features metal components for robust installation.

• Three-Axis Adjustment: Supports flexible pan, tilt and rotation positioning.

Recommended Applications

• Building perimeters

• Residential properties

• Commercial buildings

• Warehouses

• Car parks

• Driveways and entrances

• Industrial facilities

• Schools and educational facilities

• Retail premises

• Outdoor storage areas

• Gates and access points

• High-value property surveillance

• Coastal and moderately corrosive environments

• Active deterrence security installations

• Professional IP CCTV systems
