4-megapixel ColorVu fixed turret network camera-DS-2CD1347G2H-LIUF/SRB(2.8mm)

Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) – 4MP ColorVu Smart Hybrid Light Fixed Turret Network Camera with Red & Blue Light

The Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) is a professional 4MP ColorVu Smart Hybrid Light Fixed Turret Network Camera with Red and Blue Warning Light, designed for reliable and intelligent video surveillance in residential, commercial, industrial, and outdoor security environments. The Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) combines 4MP high-resolution imaging, ColorVu technology, Smart Hybrid Light, built-in audio, intelligent human and vehicle detection, and red-and-blue flashing illumination in a compact turret design. Hikvision's datasheet specifically identifies the /SRB variant as having red and blue light, while the /SL variant uses white light.

The Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) uses a 1/3-inch Progressive Scan CMOS image sensor with a maximum resolution of 2560 × 1440 pixels, providing detailed 4MP surveillance video. The high-resolution sensor allows the Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) to capture clear images for monitoring entrances, shops, offices, compounds, walkways, parking areas, and other important locations.

Featuring a 2.8mm fixed focal lens, the Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) provides approximately a 96° horizontal field of view, 52° vertical field of view, and 114° diagonal field of view. This wide-angle lens makes the Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) suitable for monitoring broad areas while maintaining detailed 4MP image quality.

The Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) features ColorVu technology with an F1.0 aperture to enhance low-light colour imaging. It also incorporates Smart Hybrid Light, combining IR and white-light illumination with a range of up to 30 metres. This allows the Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) to provide flexible nighttime surveillance according to the lighting conditions of the monitored area.

A key feature of the Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) is its integrated red-and-blue flashing light system. The /SRB model is specifically designed with red and blue warning lights, making the Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) particularly suitable for security applications where visual warning or deterrence is required.

For improved image quality, the Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) supports 120 dB WDR, BLC, HLC, and 3D DNR. These technologies help maintain clearer images in scenes with strong backlighting, shadows, headlights, and other challenging lighting conditions.

The Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) also supports intelligent motion detection with human and vehicle target classification, helping security systems focus on relevant events rather than ordinary movement. The camera includes mono audio and supports multiple audio compression formats for compatible surveillance applications.

The Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) supports H.265+, H.265, H.264+, and H.264 video compression, helping optimize bandwidth and storage usage. It provides a 10/100 Mbps self-adaptive Ethernet interface and supports PoE, allowing convenient network connectivity and power delivery through Ethernet.

Designed for outdoor surveillance, the Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) features an IP67-rated housing for protection against dust and water. It operates from approximately -30°C to 60°C, making the camera suitable for demanding environmental conditions.

If you need a professional IP surveillance camera with 4MP ColorVu imaging, Smart Hybrid Light, red-and-blue warning illumination, human and vehicle detection, audio, 120 dB WDR, PoE, and IP67 protection, the Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) is an excellent choice for modern security installations.

Key Specifications

Image Sensor: 1/3" Progressive Scan CMOS
Maximum Resolution: 2560 × 1440 pixels / 4MP
Lens: 2.8mm fixed focal lens
Lens Mount: M12
Minimum Illumination: 0.001 Lux @ F1.0, AGC ON; 0 Lux with light
Field of View: 96° horizontal, 52° vertical, 114° diagonal
Aperture: F1.0 fixed aperture
Supplement Light: IR and white light / Smart Hybrid Light
Supplement Light Range: Up to 30 metres
Day/Night: IR cut filter
WDR: 120 dB
Image Enhancement: BLC / HLC / 3D DNR
Video Compression: H.265+ / H.265 / H.264+ / H.264
Audio: Mono sound / Built-in audio capability
Smart Detection: Human and vehicle target classification
Warning Light: Red and blue flashing light
Network Interface: RJ45 10/100 Mbps self-adaptive Ethernet
Power Supply: 12V DC ±25% / PoE
Power Consumption: Maximum approximately 7.5W with PoE
Protection: IP67 weather-resistant housing
Camera Type: 4MP ColorVu Smart Hybrid Light fixed turret network camera
Adjustment: Pan 0–360°, Tilt 0–75°, Rotation 0–360°
Installation: Indoor and outdoor surveillance

Key Features

• 4MP high-resolution imaging delivers detailed 2560 × 1440 surveillance video.

• ColorVu technology provides enhanced colour imaging in low-light conditions.

• F1.0 large aperture allows more light to reach the image sensor.

• 2.8mm fixed lens provides a wide 96° horizontal viewing angle.

• Smart Hybrid Light combines infrared and white-light illumination.

• Up to 30m supplemental illumination supports effective nighttime surveillance.

• Red and blue flashing light provides a visible warning and deterrent function on the SRB variant.

• Human and vehicle classification helps improve motion-detection accuracy.

• 120 dB WDR improves visibility in scenes containing bright and dark areas.

• BLC and HLC help compensate for difficult backlight and high-light conditions.

• 3D DNR helps reduce image noise and produce clearer footage.

• Built-in audio capability adds audio monitoring to compatible surveillance systems.

• H.265+ compression helps reduce network bandwidth and storage requirements.

• PoE support allows power and network connectivity through a single Ethernet cable.

• IP67 protection helps protect the camera against dust and water.

• Wide operating temperature range from approximately -30°C to 60°C supports demanding installations.

• Compact turret design provides a professional and practical surveillance solution.

Recommended Applications

The Hikvision DS-2CD1347G2H-LIUF/SRB(2.8mm) is suitable for:

• Residential homes and compounds

• Shops and retail stores

• Offices and business premises

• Warehouses and storage facilities

• Schools and educational institutions

• Hotels and commercial buildings

• Parking areas

• Building entrances

• Reception areas

• Driveways

• Industrial facilities

• Construction sites

• Perimeter surveillance

• Security-sensitive locations

• Outdoor commercial properties

• General IP CCTV installations
